4.1 Charging the battery with a stationary charger
Charging the battery
Requirements
– Expose the battery, see page 46.
Procedure
• Disconnect the battery connector (46) from the truck connector.
• Connect the battery connector (46) to the charging cable (47) of the stationary
charger.
• Start charging in accordance with the charger operating instructions.
The battery is charging.
Completing battery charging, restoring the truck to operation
NOTICE
If charging has been interrupted, the full battery capacity will not be available.
Requirements
– The battery is fully charged.
Procedure
• Complete charging in accordance with the charger operating instructions.
• Disconnect the battery connector (46) from the charging cable (47) of the
stationary charger.
• Attach the battery connector (46) to the industrial truck.
The truck is now ready for operation.
49
04.19 en-GB
