B Truck Description
1 Application
The industrial truck is an electric pallet truck with a folding platform.
It is designed for lifting and transporting goods on level floors. Wheel arm lift
(ERC 212z/214z/216z only) increases the ground clearance when transporting
goods on uneven surfaces. Loads can be stacked or unstacked up to 5.35 m high
and transported over long distances. The rated capacity of the truck is shown on the
identification plate or the data capacity plate Qmax.
1.1 Truck models and rated capacity
The rated capacity depends on the model. The rated capacity can be derived from
the model name.
ERC Model name
2 Series
14 Rated capacity x 100 kg
z Initial lift
The rated capacity is not generally the same as the permissible capacity. The
permissible capacity can be found on the capacity plate attached to the truck.
15
04.19 en-GB
