4.5 Checking the hydraulic oil level
Check oil level
Requirements
– Lower the load handler.
– Prepare the truck for maintenance and repairs, see page 179.
Procedure
• Lift off the front panel, see page 180
• Check the oil level in the hydraulic reservoir.
Z
There are markings on the hydraulic reservoir. The oil level must be checked
when the load handler and support-arm lift are lowered.
• If necessary, add transmission oil of the correct grade, see page 178(refer to
table).
Z
For the first filling approximately 0,6 l more hydraulic oil should be added.
The oil level has now been checked.
Z
If a leak is discovered in the hydraulics (cylinder; unions, lines), the truck must be
decommissioned and repaired by specialist personnel.
Mark Litres Lift heights (h
3
)
ZT ZZ DZ
3 Approx. 8.3 - - -
2 Approx. 7.5 - - ERC 214-216
1 Approx. 6.5 ERC 212-216 ERC 212-216 ERC 212
Mark Litres Lift heights (h
3
)
ZT ZZ DZ
3 Approx. 8.3 - - -
2 Approx. 7.5 - - ERC
214z-216z
1 Approx. 6.5 ERC
212z-216z
ERC
212z-216z
ERC 212z
185
04.19 en-GB
