Maintaining the EX4650 Cooling System
IN THIS SECTION
Removing a Fan Module from an EX4650 Switch | 109
Installing a Fan Module in an EX4650 Switch | 110
Removing a Fan Module from an EX4650 Switch
The fan module in EX4650 switches is a hot-removable and hot-insertable field-replaceable unit (FRU)
installed in the rear panel of the switch: You can remove and replace it without powering off the switch
or disrupting switch functions.
Ensure that you have the following parts and tools available:
•
Phillips (+) screwdriver, number 2
•
An antistatic bag or an antistatic mat
•
A replacement fan module
NOTE: The fan module slots are at the left side of the rear panel.Figure 46 on page 110 shows how
to remove a fan module.
1. Place the antistatic bag or the antistatic mat on a flat, stable surface.
2. Loosen the captive screws on the front faceplate of the fan module by using your fingers. If you are
unable to loosen the captive screws by using your fingers, use the screwdriver.
WARNING: To prevent injury, do not touch the fan with your hands or any tools as
you slide the fan module out of the chassis—the fan might still be running.
3. Grasp the handle on the fan module and pull it firmly to slide the fan module out of the chassis.
4. Place the fan module in the antistatic bag or on the antistatic mat placed on a flat, stable surface.
109
