Step 2: Install the Mounting Hardware
1. Slide the four-post rack mounting shelf between the rack rails, resting the bottom of
the shelf on the rack supports. The four-post rack mounting shelf installs on the rear
rack rails, extending toward the front of the rack, as specified in the MX2020 3D
Universal Edge Router Hardware Guide, for large shelf installation.
NOTE: The two brackets on the four-post rack mounting shelf are
adjustable from 24 in. (60.96 cm) through 30 in. (76.2 cm) to
accommodate different types of racks rails.
2. On the front of the rear rack rails, partially insert screws into the holes in each ear of
the four-post rack mounting shelf (see Figure 5 on page 12).
NOTE: Depending on the type of rack or cabinet you have, cage nuts might
be required.
3. Partially insert screws into the open holes in the front ears of the four-post rack
mounting shelf.
4. Tighten all the screws completely.
11Copyright © 2015, Juniper Networks, Inc.
