Install the Pallet Jack Attachment
1. Remove the pallet jack attachment from the shipping crate.
2. Place the pallet jack attachment across both pallet jack legs.
3. Using a 9/16-in. (14 mm) socket wrench, loosen and remove the eight shipping bracket
support torque fasteners that are located on the top of the pallet jack attachment
platform.
4. Using a 9/16-in. (14 mm) socket wrench, loosen the torque fasteners that are located
on the four adjustable pallet jack attachment brackets.
5. Adjust the four pallet jack attachment brackets until they fit under the pallet jack legs.
6. Tighten the torque fasteners by using a 9/16-in. (14 mm) socket wrench to secure the
brackets on the pallet jack attachment to the pallet jack (see Figure 13 on page 23).
Figure 13: Installing MX2020 Pallet Jack Attachment
23Copyright © 2015, Juniper Networks, Inc.
