Step 1: Prepare the Site for Installation
•
Rack-Mounting Requirements on page 4
•
Moving Requirements and Guidelines Using a Router Transport Kit on page 6
•
Tools Required to Unpack and Prepare the MX2020 Router for Installation on page 9
Rack-Mounting Requirements
•
You can install the router in a four-post rack or cabinet.
NOTE: The shipping and installation site must be an ESD-approved area.
•
The rack rails must be spaced wide enough to accommodate the router chassis's
external dimensions: 78.75 in. (200 cm) high, 36.22 in. (92 cm) deep, and
19 in. (48.3 cm) wide (see Figure 1 on page 6).
NOTE: A typical four-post rack measures 84 in. (213.4 cm) high,
24 in. (61 cm) to 30 in. (76.2 cm) deep, and 19 in. (48.3 cm) wide.
NOTE: The dimensions also include the standard and extended cable
manager systems and standard EMI covers.
•
The rack must be able to accommodate the additional depth of the extended cable
manager system, 40.15 in. (102 cm) deep (see Figure 1 on page 6).
•
The rack must be strong enough to support the weight of the fully populated router.
See Table 1 on page 4 for MX2020 shipping weight specifications.
Table 1: MX2020 Shipping Weight Specifications
Shipping WeightItem
527 lb (239.04 kg)Shipping crate and pallet
429.6 lb (194.86 kg)Unpopulated MX2020
956.6 lb (433.9 kg)Unpopulated MX2020 with shipping crate and
pallet
1515 lb (687.19 kg)Fully populated MX2020
2042 lb (926.23 kg)Fully populated MX2020 with shipping crate
and pallet
Copyright © 2015, Juniper Networks, Inc.4
MX2020 3D Universal Edge Router Quick Start
