Mounting
Page Operating Instructions for Powador .-. TL_EN
ENEN
Authorised electrician
Key
A
horizontal distance between the two inverters / vertical distance
between inverter and the ceiling
cm
B Distance in front 100 cm
C Vertical distance to an additional inverter suitable for wall mounting 70 cm
Drilling the holes
. Mark (x) drill holes on bottom.
. For wall mounting: Mark the position of the holes on the wall (x) and insert the wall anchors in the wall for
additional security.
. Drill the holes. Floor: mm diameter, wall: mm diameter.
» Install and secure the inverter.
. Fitting the housing (.-. TL)
Removing the EMC sheet metal
. Unscrew the M x screws from the EMC sheet metal.
. Remove and store the EMC sheet metal.
Install the hood.
Installing the hood
ඣ Remove the EMC sheet metal.
. Place the hood on the top side of the housing.
. Secure the hood to the inverter housing from the inside using the enclosed fastening screws.
» Install the side housing covers.
Installing the side housing covers
ඣ Remove the EMC sheet metal.
. Place the left housing cover on the inverter housing.
. Secure the left housing cover to the inverter housing from the inside using the enclosed M x screws.
. Place the right housing cover on the inverter housing.
. Secure the right housing cover to the inverter housing from the inside using the enclosed M x screws
with a Torx T screw driver.
» Place the EMC sheet metal on the housing.
Placing the EMC sheet metal on the housing
. Place the EMC sheet metal on the inverter housing.
. Secure the EMC sheet metal to the inverter housing using the enclosed M x screws.
» The mounting of the inverter is complete.
» Continue with the installation.
. Securing the unit
Securing the inverter
. Position the inverter above the drill holes.
. Use the four anchoring bolts to secure the inverter to the oor.
. For installations at a wall: secure the inverter to the wall with two screws.
» Install the housing.
