PRODUCT DESCRIPTION
2.4 Part code
x x x x x x x - x x x x
Heat sink design
A: Air cooler with internal fan power supply
D: Air cooler with external fan power supply
V: Liquid cooling system as built-in version
W: Liquid cooling system as push-through version
Z:
Liquid cooling system with stainless steel tubes as
built-in version
At special/customer unit consecutive numbering
Encoder interface
0: Without encoder interface
M: Multi encoder (only F6)
At special/customer unit consecutive numbering
Switching frequency,
Current controller limit,
Overcurrent
0: 2 kHz / 125 % / 150 %
1: 4 kHz / 125 % / 150 %
4: 2 kHz / 150 % / 180 %
2: 8 kHz / 125 % / 150 %
At special/customer unit consecutive numbering
Voltage /
Connection
9: 3ph 400 V AC
B: 3ph 690 V AC
D: 690 V DC without precharging
V: 400 V DC without precharging
At special/customer unit consecutive numbering
Housing P
Variants
0: Without braking transistor
1: With braking transistor
A: Such as 0, but control board with safety relay
B: Such as 1, but control board with safety relay
Control type
A: V/f software F5+ without STO
E: SCL software F5+ without STO
H: ASCL software F5+ without STO
K: V/f software F5+ with STO / F6 with EtherCAT
1)
P: SCL software F5+ with STO
L: ASCL software F5+ with STO
Series
F5: COMBIVERT F5
F6: COMBIVERT F6
Inverter size 28…39
Table 1: Part code
1)
EtherCAT
®
is a registered trademark and patented technology, li-
censed by Beckhoff Automation GmbH, Germany.
