3.3 Technical data 400V class
3.3.1 Single Drive
Inverter size 28 29 30
Housing P
Module number 1
Rated power
Rated motor power P
mot / kW 200 250 315
Output rated power S
out / kVA 256 319 395
Drive converter (input)
Input rated voltage U
N / V 400 (UL: 480)
Input voltage range U
in / V 305…528 ± 0 %
Phases 3
Mains frequency f
N / Hz 50 / 60 ± 2
Input rated current I
in / A 385 483 598
Input rated current UL I
in_UL / A 336 417 517
permitted mains forms TN, TT, IT
1)
,Δmains
2)
Permissible main fuse gG / gL
3)
=> Protection of drive converters
Drive converter (output)
Output voltage
4)
Uout / V 0…Uin
Output frequency
5)
fout / Hz 0...599
Min. output frequency at continuous full load f
out_min / Hz 3
Output phases
3
Output rated current I
out / A 370 460 570
Output rated current UL I
out_UL / A 320 398 493
Standstill current at 4 kHz
6)
Iout_ST / A 259 322 399
Max. short time current 30s
7)
IOL / % 125
Over current
12)
IOC / % 150 150 / 180 150
Min. switching frequency (rated switching frequency)
fS_min / kHz 2
Max. switching frequency f
S_max / kHz 8 4
Overload characteristic => Characteristics
Power dissipation
Switching frequency f
S
/ kHz 2 4 8 2 4 8 2 4
Total power dissipation
8)
PD / kW 3.5 4.1 5.4 4.3 4.9 6.8 5.3 6.2
Cable cross-section
Motor cable cross-section => Cable cross-sections
Max. motor line length shielded => Motor cable lengths
DC link data
DC link capacity C
int / μF 16200 19800
Max. external DC link capacity
9)
Cext_max / μF
19800
Precharging current
8)
Ipre / A 98
Power OFF DC U
Poff_dc / V 200
Undervoltage level DC U
UP_dc / V 240
Overvoltage level DC U
OP_dc / V 840
Operating voltage range DC
13)
U_dc / V 390...780
Input rated current DC I
in_dc / A 469 580 –
14)
Rated input current UL DC Iin_UL_dc / A 403 502 –
14)
Rated output current DC
17)
Iout_dc / A 469 580 –
Rated output current UL DC
17)
Iout_UL_dc / A 403 502 –
continued on the next page
29
TECHNICAL DATA 400V CLASS
