Keithley 2306 User Manual

11-4 DISPlay, FORMat, and SYSTem
DISPlay:TEXT:DATA <a> Define message on display
:DISPlay[:WINDow[1]]:TEXT:DATA <a>
Parameters <a> = ASCII characters for message
Types: String 'aa...a' or
"aa...a"
Indefinite Block #0aa...a
This command defines a text message for the display. A message is made up of 32 characters
and starts on the top line of the display and wraps do
wn to the bottom line. Spaces are counted
as characters and can be used to properly position the message on the display. If your message
is less than 32 characters, the appropriate number of spaces are added at the end. If your message
is greater than 32 characters, it will not be displayed. On power-up, the message is a string of 32
spaces.
An indefinite block message must be the only command in the program message or the last
comma
nd in the program message. If you include a command after an indefinite block message
(on the same line), it will be treated as part of the message and is displayed instead of executed.
NOTE Use D
ISPlay:TEXT:STATe <b> to enable the text message mode.
DISPlay:TEXT:STATe <b> Control message
:DISPlay[:WINDow[1]]:TEXT:STATe <b>
Parameters :<b> = 0 or OFF Disable text message
1 or ON Enable text message
This command enables or disables the text message mo
de. When enabled, the text message
is displayed. If no message is defined, a string of 32 spaces is displayed. When disabled, the
message is removed from display. The display returns to the normal display state.
A text message remains displayed only as long as the instrument is in remote. Taking the
instrumen
t out of remote (by pressing the LOCAL key or sending GTL) cancels the message and
disables the text message mode.
FORMat subsystem
The commands for this subsystem are used to select the data format for transferring
instrument readings over the bus. These commands are summarized in Table 11-2.
Table 11-2
SCPI commands — data format
Command Description Default
FORMat
[:DATA] <type>
:BORDer <name>
Specify data format; ASCii, SREal or DREal.
Specify byte order; NORMal or SWAPped.
ASCii
SWAP
