13 SERVICE WORK ON THE CHASSIS 142
13.21 Positioning the mask spoiler
V00125-10
–
Push the two rear catches

on the mask spoiler into the supports

provided.
–
Push the mask spoiler up and position catch

in bracket

.
Info
Ensure that the turn signal cable is placed correctly.
Carefully push the mask spoiler up to avoid breaking the component or bending
catch

.
Make sure that the rear catches on the mask spoiler remain in the supports pro-
vided.
V00115-11
– Push the front part of the mask spoiler laterally into the supports.

KTM 1290 Super Adventure Specifications

General

Displacement	1301 cc
Transmission	6-speed
Power	160 hp (118 kW)
Torque	138 Nm
Fuel Capacity	23 liters
Front Suspension	WP Semi-active Suspension
Rear Suspension	WP Semi-active Suspension
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	267 mm disc, 2-piston caliper
ABS	Yes
Traction Control	Yes, MTC (Motorcycle Traction Control)
Wheelbase	1, 560 mm
