KTM 1290 Super Adventure User Manual

8 ERGONOMICS 77
8.2 Handlebar position
401666-11
The holes on the handlebar support are placed at a distance of

from the center.
Hole distance

3.5 mm (0.138 in)
The handlebar can be mounted in two different positions. In this way, the handlebar can be
mounted in the position that is most comfortable for the rider.
8.3 Adjusting the handlebar position
Warning
Danger of accidents Handlebar breakage.
– If the handlebar is bent or straightened it will cause material fatigue, and the handlebar can break. Always replace handlebar.
308080-01
–
Remove screws

. Remove the handlebar clamps. Remove the handlebar and lay it to
one side.
Info
Cover the components to protect them against damage.
Do not bend the cables and lines.
–
Remove screws

. Take off the handlebar supports.
–
Place the handlebar supports in the required position. Mount and tighten screws

.

KTM 1290 Super Adventure Specifications

General

Displacement	1301 cc
Transmission	6-speed
Power	160 hp (118 kW)
Torque	138 Nm
Fuel Capacity	23 liters
Front Suspension	WP Semi-active Suspension
Rear Suspension	WP Semi-active Suspension
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	267 mm disc, 2-piston caliper
ABS	Yes
Traction Control	Yes, MTC (Motorcycle Traction Control)
Wheelbase	1, 560 mm
