KTM 1290 Super Adventure User Manual

16 ELECTRICAL SYSTEM 202
402424-10
–
Set the headlight to marking

.
Guideline
The light-dark boundary must lie exactly on the lower mark

when the motorcycle
is ready to operate with the rider mounted along with any luggage and a passenger if
applicable.
Finishing work
– Install the bottom triple clamp cover. ( p. 130)
16.15 Adjusting the cornering light range
Preparatory work
– Check the setting of the lighting system. ( p. 199)
Main work
– Press the UP or DOWN button until the "Settings" menu appears on the matrix display.
Pressing the SET button opens the menu.
– Press the UP or DOWN button until "cLightTest" is highlighted in black on the matrix dis-
play. Pressing the SET button again starts the cornering light test.
– Wait for a few seconds until the upper segment of the left cornering light lights up con-
tinuously.

KTM 1290 Super Adventure Specifications

General

Displacement	1301 cc
Transmission	6-speed
Power	160 hp (118 kW)
Torque	138 Nm
Fuel Capacity	23 liters
Front Suspension	WP Semi-active Suspension
Rear Suspension	WP Semi-active Suspension
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	267 mm disc, 2-piston caliper
ABS	Yes
Traction Control	Yes, MTC (Motorcycle Traction Control)
Wheelbase	1, 560 mm
