22 TECHNICAL DATA 120
22.1 Engine
22.1.1 All 125 models
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake and
exhaust control
Displacement 124.8 cm³ (7.616 cu in)
Stroke 54.5 mm (2.146 in)
Bore 54 mm (2.13 in)
Crankshaft bearing 1 grooved ball bearing/1 roller bearing
Conrod bearing Needle bearing
Piston pin bearing Needle bearing
Pistons Aluminum cast
Piston rings 2 half keystone rings
X (upper edge of piston to upper edge of cylinder) 0… 0.10 mm (0… 0.0039 in)
Z (height of control flap) 43.7 mm (1.72 in)
Primary transmission 23:73
Clutch Multidisc clutch in oil bath/hydraulically activated
Gearbox 6-gear, claw shifted
Transmission ratio
1st gear 12:33
2nd gear 15:31
3rd gear 17:28
4th gear 19:26
5th gear 21:25
6th gear 20:20
Ignition Contactless controlled fully electronic ignition with digital igni-
tion adjustment, type Kokusan
Spark plug NGK BR9 ECMVX
Spark plug electrode gap 0.60 mm (0.0236 in)
Starting aid Kick starter
22.1.2 All 200 models
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake and
exhaust control
Displacement 193 cm³ (11.78 cu in)
Stroke 60 mm (2.36 in)
Bore 64 mm (2.52 in)
Crankshaft bearing 1 grooved ball bearing/1 roller bearing
Conrod bearing Needle bearing
Piston pin bearing Needle bearing
Pistons Aluminum cast
Piston rings 2 half keystone rings
X (upper edge of piston to upper edge of cylinder) 0… 0.10 mm (0… 0.0039 in)
Z (height of control flap) 47 mm (1.85 in)
Primary transmission 23:73
Clutch Multidisc clutch in oil bath/hydraulically activated
Gearbox 6-gear, claw shifted
Transmission ratio
1st gear 12:33
2nd gear 15:31
3rd gear 17:28
4th gear 19:26
5th gear 17:19
