22 TECHNICAL DATA 123

Axle for control flap, exhaust control M8 Step 1

3 Nm (2.2 lbf ft)

Step 2 (loosen, counter-

clockwise)

1/4 turn

–

Nut, cylinder base M8 30 Nm (22.1 lbf ft) –

Screw, kick starter M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, shift drum locating M8 25 Nm (18.4 lbf ft) Loctite

243™

Stud, cylinder base M8 35 Nm (25.8 lbf ft) –

Drain plug, water pump cover M10x1 15 Nm (11.1 lbf ft) –

Gear oil drain plug M10x1 15 Nm (11.1 lbf ft) –

Nut, rotor M12x1 60 Nm (44.3 lbf ft) –

Gear oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –

Spark plug M14x1.25 25 Nm (18.4 lbf ft) –

Nut, primary gear M16LHx1.5 130 Nm (95.9 lbf ft) Loctite

243™

Nut, inner clutch hub M18x1.5 130 Nm (95.9 lbf ft) Loctite

243™

Cap nut, exhaust control M26x1 35 Nm (25.8 lbf ft) –

22.2.2 All 250/300 models

Screw, clamping plate EJOT DELTA PT

30x6 1 Nm (0.7 lbf ft) –

Screw, membrane core plate EJOT DELTA PT

30x12 1 Nm (0.7 lbf ft) –

Screw, membrane holder EJOT DELTA PT

35x25 1 Nm (0.7 lbf ft) –

Screw, angle lever, exhaust control M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, clutch spring retainer M5 6 Nm (4.4 lbf ft) –

Screw, crankshaft position sensor M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, exhaust control cap M5 5 Nm (3.7 lbf ft) –

Screw, exhaust control cover M5 6 Nm (4.4 lbf ft) –

Screw, locking lever M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, retaining bracket of exhaust

control

M5 7 Nm (5.2 lbf ft) Loctite

2701™

Screw, water pump wheel M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, alternator cover M6 8 Nm (5.9 lbf ft) –

Screw, bearing retainer M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, clutch cover M6 10 Nm (7.4 lbf ft) –

Screw, control flap, exhaust control M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, engine case M6 10 Nm (7.4 lbf ft) –

Screw, exhaust flange M6 8 Nm (5.9 lbf ft) –

Screw, gear oil level check M6 10 Nm (7.4 lbf ft) –

Screw, intake flange/reed valve housing M6 10 Nm (7.4 lbf ft) –

Screw, intermediate wheel bolt M6 8 Nm (5.9 lbf ft) Loctite

648™

Screw, kick starter spring M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, kick starter stop plate M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, shift drum locating M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, shift lever M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, slave cylinder of the clutch M6 10 Nm (7.4 lbf ft) –

Screw, starter motor M6 8 Nm (5.9 lbf ft) –

Screw, stator M6 8 Nm (5.9 lbf ft) Loctite

243™

Screw, water pump cover M6 10 Nm (7.4 lbf ft) –

Screw, cylinder head M8 27 Nm (19.9 lbf ft) –

Screw, kick starter M8 25 Nm (18.4 lbf ft) Loctite

2701™

Nut, cylinder base M10 35 Nm (25.8 lbf ft) –

Drain plug, water pump cover M10x1 15 Nm (11.1 lbf ft) –

Nut, rotor M12x1 60 Nm (44.3 lbf ft) –

Starter	Kickstarter
Transmission	6-speed
Front Brake	Disc brake
Rear Brake	Disc brake
Cooling System	Liquid-cooled
Engine Type	2-stroke
