CONTROLS (EXC‑F, EXC‑F SIX DAYS, XCF-W) 15
6.1Speedometer
400312-01
– Press the key to change the display mode or change to one of the setup menus.
– Press the button to control different functions.
– Press the button to control different functions.
Info
In its condition at delivery, the display mode SPEED/H andSPEED/ODO is acti-
vated.
6.2Speedometer activation and test
400313-01
Activating the speedometer:
The speedometer is activated when one of the keys is pressed or a signal is received
from the wheel speed sensor.
Display test
For the function test of the display, all display segments light up briefly.
400314-01
WS (wheel size)
After the display function test, the wheel size WS is displayed briefly.
Info
2205 mm corresponds to the size of the 21" front wheel with a series produc-
tion tire.
The display then changes to the last selected mode.
6.3Tripmaster switch
(Option: Tripmaster switch)
You can use the trip master switch to control the functions of the speedometer from the handlebar.
Info
The trip master is an optional accessory.
6.4Setting kilometers or miles
Info
If you change the unit of measure, the ODO value is retained and converted accordingly.
The values TR1, TR2, A1, A2 and S1 are cleared when the unit of measure is changed.
Condition
The motorcycle is stationary.
400329-01
– Press the button briefly and repeatedly until H appears at the bottom right of the
display.
– Press the button for 3 - 5 seconds.
The Setup menu opens and the active functions are displayed.
– Press the button repeatedly until the Km/h/Mph display flashes.
Adjusting Km/h
– Press the button .
Adjusting Mph
– Press the button .
