21 TROUBLESHOOTING
152
Faults Possible cause Action
The engine cannot be cranked
(starter motor)
Operating error – Carry out start procedure. ( p. 43)
12-V battery discharged – Charge the 12-V battery. ( p. 123)
– Check charging voltage.
– Check the open-circuit current.
– Check the stator winding of the alter-
nator.
Main fuse blown – Change the main fuse. ( p. 125)
Starter relay defective – Check the starter relay.
Starter motor defective – Check the starter motor.
The engine turns but does not
start
Operating error – Carry out start procedure. ( p. 43)
The plug-in connection of the
fuel hose connection is not
connected
– Connect the plug-in connection of the
fuel line.
Fuse 1 blown – Change the fuses of individual power
consumers. ( p. 126)
Fuse 4 blown – Change the fuses of individual power
consumers. ( p. 126)
Idle speed is not set correctly – Adjust the idle speed. ( p. 140)
Spark plug oily or wet – Clean and dry the spark plug or replace
if necessary.
Plug gap of spark plug too wide – Adjust plug gap.
Guideline
Spark plug electrode gap
1.0 mm (0.039 in)
Ignition system defective – Check the ignition system.
Short-circuit cable in wiring
harness frayed, switch-off but-
ton or emergency OFF switch
faulty
– Check the wiring harness. (visual
check)
– Check the electrical system.
Error in the electronic fuel
injection
– Read out the fault memory using the
KTM diagnostics tool.
Engine does not speed up Error in the electronic fuel
injection
– Read out the fault memory using the
KTM diagnostics tool.
Ignition system defective – Ignition coil - check the secondary
winding.
– Check the spark plug connector.
– Check the stator winding of the alter-
nator.
Engine has too little power Air filter heavily contaminated – Clean the air filter and air filter box.
( p. 82)
Fuel filter is very dirty – Change the fuel filter.
Fuel screen is very dirty – Change the fuel screen. ( p. 143)
Error in the electronic fuel
injection
– Read out the fault memory using the
KTM diagnostics tool.
Exhaust system leaky,
deformed or too little glass
fiber yarn filling in the main
silencer
– Check exhaust system for damage.
– Change the glass fiber yarn filling of
the main silencer. ( p. 85)
