ELECTRICAL SYSTEM 137
700602-01
– Position the cover.
– Mount and tighten screws .
– Check that the license plate lamp is functioning properly.
13.12Checking the headlight setting
400726-10
– Park the vehicle on a horizontal surface in front of a light-colored wall and make a mark
at the level of the center of the headlight.
– Make another mark at a distance of under the first mark.
Guideline
Distance 5 cm (2 in)
– Park the vehicle at a distance of vertically in front of the wall and switch on the low
beam headlight.
Guideline
Distance 5 m (16 ft)
– The rider, with luggage and passenger if applicable, now mounts the motorcycle.
– Check the headlight setting.
The light-dark boundary must lie exactly on the lower mark when the motorcycle is
ready to operate with the rider mounted along with any luggage and a passenger if
applicable.
