SERVICE WORK ON THE CHASSIS 93
101166-10
– Adjust the basic setting of the clutch lever to your hand size by turning adjusting
screw .
10.17Checking/rectifying the fluid level of the hydraulic clutch
Info
The fluid level rises with increasing wear of the clutch lining disc.
Do not use brake fluid.
101167-10
– Move the clutch fluid reservoir mounted on the handlebar to a horizontal position.
– Remove screws .
– Remove cover with membrane .
– Check the fluid level.
Fluid level below top edge of container 4 mm (0.16 in)
» If the coolant level does not meet specifications:
– Correct the fluid level of the hydraulic clutch.
Hydraulic fluid (15) ( p. 196)
– Position the cover with the membrane. Mount and tighten the screws.
