TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 191

Screw, rear side part EJOT Initial screw connection

3.3 Nm (2.43 lbf ft)

Subsequent screw connec-

tion

2 Nm (1.5 lbf ft)

–

Screw, side stand switch M4 2 Nm (1.5 lbf ft)

Loctite

243™

Remaining chassis screws M5 5 Nm (3.7 lbf ft) –

Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –

Screw, closure flange, fuel tank M5 3.3 Nm (2.43 lbf ft) –

Screw, engine oil level viewer M5 3.3 Nm (2.43 lbf ft) –

Screw, foot brake lever stub M5 6 Nm (4.4 lbf ft)

Loctite

243™

Nut, tail light M6 8 Nm (5.9 lbf ft) –

Remaining chassis nuts M6 15 Nm (11.1 lbf ft) –

Remaining chassis screws M6 10 Nm (7.4 lbf ft) –

Screw, chain sliding guard M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, fuel pump M6 6 Nm (4.4 lbf ft) –

Screw, fuel tap M6 6 Nm (4.4 lbf ft) –

Screw, magnetic holder on side stand M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, seat bracket, fuel tank M6 3.3 Nm (2.43 lbf ft) –

Screw, splash protector M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, spoiler M6 3.3 Nm (2.43 lbf ft) –

Remaining chassis nuts M8 30 Nm (22.1 lbf ft) –

Remaining chassis screws M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –

KTM 990 SupermotoR User Manual
