TECHNICAL DATA - CHASSIS 187

Tail light W5W/socket W2.1x9.5d 12 V

5 W

Brake light P21W/socket BA15s 12 V

21 W

License plate lamp W5W/socket W2.1x9.5d 12 V

5 W

24.2Tires

Front tire Rear tire

120/70 ZR 17 M/C 58W TL

Pirelli DRAGON SUPERCORSA PRO

180/55 ZR 17 M/C 73W TL

Pirelli DRAGON SUPERCORSA PRO

Additional information is available in the Service section under:

http://www.ktm.com

24.3Capacity - fuel

Total fuel tank capacity, approx. 15 l (4 US gal) Super unleaded (ROZ 95 / RON 95 / PON 91) ( p. 197)

Fuel reserve, approx. 3.5 l (3.7 qt.)

Table of Contents5
Table of Contents8
Means of Representation9
Important Information10
- Overview of Labels14
View of Vehicle24
- View of Vehicle, Front Left Side (Vehicle Differs Slightly from Photo)24
- View of Vehicle, Rear Right Side (Vehicle Differs Slightly from Photo)26
Serial Numbers28
- Chassis Number/Type Label28
- Key Number29
- Engine Number30
- Fork Part Number30
- Shock Absorber Part Number31
Controls32
- Clutch Lever32
- Hand Brake Lever32
- Throttle Grip33
- Light Switch33
- Headlight Flasher Switch34
- Turn Signal Switch34
- Horn Button35
- Ignition/Steering Lock35
- Immobilizer36
- Emergency off Switch36
- Electric Starter Button37
- Combination Instrument37
- Combination Instrument - Function Buttons38
- Combination Instrument - Tachometer38
- Combination Instrument - Indicator Lamps39
- Combination Instrument - Display40
- Combination Instrument - Speedometer41
- Setting Kilometers or Miles41
- Combination Instrument - Time42
- Setting the Clock42
- Combination Instrument - ODO Display43
- Combination Instrument - Setting/Resetting TRIP 143
- Combination Instrument - Setting/Resetting TRIP 244
- Combination Instrument - TRIP F Display45
- Combination Instrument - Ambient Temperature Display45
- Setting the Temperature Units46
- Combination Instrument - Warning of Slippery Roads46
- Combination Instrument - Coolant Temperature Indicator47
- Opening the Filler Cap47
- Closing the Filler Cap48
- Handrails49
- Seat Lock49
- Tool Set50
- Helmet Lock50
- Passenger Footrests51
- Shift Lever51
- Foot Brake Lever52
- Side Stand53
Preparing for Use54
- Information on First Use54
- Running in the Engine55
- Loading the Vehicle55
Riding Instructions58
- Checks and Maintenance Measures When Preparing for Use58
- Starting59
- Starting off60
- Shifting, Riding61
- Braking64
- Stopping, Parking65
- Refueling67
Service Schedule69
Tuning the Chassis72
- Fork/Shock Absorber72
- Adjusting the Compression Damping of the Fork72
- Adjusting the Rebound Damping of the Fork73
- Adjusting the Spring Preload of the Fork74
- Compression Damping of the Shock Absorber76
- Adjusting the Low-Speed Compression Damping of the Shock Absorber76
- Adjusting the High-Speed Compression Damping of the Shock Absorber77
- Adjusting the Rebound Damping of the Shock Absorber78
- Adjusting the Spring Preload of the Shock Absorber79
- Service Work on the Chassis81
- Raising the Motorcycle with the Front Wheel Stand81
- Taking the Motorcycle off of the Front Wheel Stand81
- Raising the Motorcycle with the Rear Wheel Stand82
- Taking the Motorcycle off of the Rear Wheel Stand82
- Bleeding the Fork Legs83
- Removing the Seat83
- Mounting the Seat84
- Mounting the Helmet Lock on the Vehicle84
- Reinstalling the Fuel Tank85
- Positioning the Fuel Tank86
- Checking the Chain for Dirt88
- Cleaning the Chain88
- Checking the Chain Tension89
- Adjusting the Chain Tension90
- Checking the Chain, Rear Sprocket and Engine Sprocket92
- Adjusting the Basic Position of the Clutch Lever94
- Checking/Rectifying the Fluid Level of the Hydraulic Clutch95
Brakes96
- Adjusting the Basic Position of the Hand Brake Lever96
- Checking the Front Brake Discs96
- Checking the Front Brake Fluid Level97
- Adding Front Brake Fluid98
- Brake Linings99
- Checking the Front Brake Linings99
- Checking the Free Travel of the Foot Brake Lever100
- Checking the Rear Brake Disc101
- Checking the Rear Brake Fluid Level102
- Adding Rear Brake Fluid103
- Checking the Rear Brake Linings104
Wheels, Tires106
- Removing the Front Wheel106
- Installing the Front Wheel107
- Removing the Rear Wheel109
- Installing the Rear Wheel110
- Checking Rear Hub Shock Absorbers111
- Checking the Tire Condition112
- Checking the Tire Air Pressure114
Electrical System116
- Removing the Battery116
- Installing the Battery117
- Recharging the Battery118
- Changing the Main Fuse120
- Changing the Fuses of Individual Power Consumers122
- Changing the Headlight Bulb124
- Changing the Parking Light Bulb126
- Changing the Turn Signal Bulb129
- Changing the Brake Light Bulb130
- Changing the Tail Light Bulbs134
- Changing the License Plate Lamp138
- Checking the Headlight Setting139
- Adjusting Headlight Range140
- Activating/Deactivating the Ignition Key140
Cooling System145
- Checking the Antifreeze and Coolant Level145
- Checking the Coolant Level in the Compensating Tank147
- Draining the Coolant149
- Filling/Bleeding the Cooling System150
Checking the Play in the Throttle Cable153
Tuning the Engine153
Adjusting the Play in the Throttle Cable154
- Ignition Curve Plug-In Connector154
- Adjusting the Ignition Curve to the Fuel Quality155
- Checking the Basic Position of the Shift Lever155
- Adjusting the Basic Position of the Shift Lever156
Service Work on the Engine157
- Checking the Engine Oil Level157
- Changing the Engine Oil and Filter, Cleaning the Oil Screens X158
- Draining the Engine Oil and Filter, Cleaning the Oil Screens X158
- Filling up with Engine Oil163
- Adding Engine Oil164
Cleaning, Care165
- Cleaning Motorcycle165
- Protective Treatment for Winter Operation167
Storage168
- Preparing for Use after Storage169
Troubleshooting170
Immobilizer Blink Code173
Engine Control Blink Code175
Technical Data - Engine181
- Capacity- Engine Oil182
- Capacity - Coolant182
Technical Data - Engine Tightening Torques183
Technical Data - Chassis187
- Lighting Equipment188
- Tires189
- Capacity - Fuel189
Technical Data - Fork190
Technical Data - Shock Absorber191
Technical Data - Chassis Tightening Torques193
Substances196
Auxiliary Substances200
Standards202
Index203
