II-90
WSM Minor Change II Service Engineering Section
Dual-speed piston (with shoe)
Excess padding eliminated according to the main piston shoe locus
Main piston shoe locus
Dual-speed piston (shoeless)
2. Swash plate and Hi-Low piston
