95PERIODIC SERVICE
BChanging Engine Oil
To avoid personal injury:
A Be sure to stop the engine before changing the
oil.
A Allow engine to cool down sufficiently, oil can
be hot and can burn.
1. To drain the used oil, remove the drain plug at the
bottom of the engine and drain the oil completely into
the oil pan.
All the used oil can be drained out easily when the
engine is still warm.
2. After draining reinstall the drain plug.
3. Fill with the new oil up to the upper notch on the
dipstick.
(See "LUBRICANTS" in "MAINTENANCE" section.)
Oil
capacity
with filter
L3240 5.7 L (6.0 U.S.qts.)
L3540 6.7 L (7.1 U.S.qts.)
L3940, L4240, L4740 8.2 L (8.7 U.S.qts.)
L5040, L5240, L5740 9.4 L (9.9 U.S.qts.)
(1) Oil inlet
(2) Dipstick
(A) Oil level is acceptable within this range
(1) Drain plug
(1) Drain plug
