Kubota L3940 - Front Wheels (with 4 Wheel Drive)

9TIRES, WHEELS AND BALLAST
BFront Wheels (with 4 wheel drive)
Front tread can not be adjusted.
A Do not turn front discs to obtain wider tread.
A When re-fitting or adjusting a wheel, tighten the bolts
to the following torques then recheck after driving the
tractor 200 m (200 yards) and 10 times of shuttle
movement by 5 m (5 yards), and thereafter according
to service interval.
(See "MAINTENANCE" section.)
A Wheels with beveled or tapered holes: Use the
tapered side of lug nut.
(1) [L3240, L3540, L4240]
137 N-m (14 kgf-m)
[L5240, L5740]
185 N-m (19 kgf-m)
Models L3240, L3540
Tires
7-16
Farm
---
---
212/80-D15
Turf
--- ---
Tread 1150 mm ---
---
1180 mm
--- ---
Models L4240
Tires
---
8-16
Farm
--- --- ---
29 x 12.50-15
Turf
Tread
---
1145 mm
--- --- ---
1280 mm
Models L5240, L5740
Tires
--- ---
9.5-16
Farm
---
29 x 12.00-15
Turf
29 x 12.50-15
Turf
Tread
--- ---
1340 mm
---
1415 mm 1425 mm
