12 IMPLEMENT LIMITATIONS
IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by KUBOTA.
Use with implements which are not sold or approved by KUBOTA and which exceed the maximum specifications listed
below, or which are otherwise unfit for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor,
damage to other property and injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use
with improper implements are not covered by the warranty.]
A Implement size may vary depending on soil operating conditions.
Tread (max.width) with farm tires
Lower link end max. lifting
capacity W0
Front
Rear
2WD 4WD
L3240 1610 mm (63.4 in.)
1155 mm (45.5 in.)
1480 mm (58.3 in.) 1700 kg (3750 lbs.)
L3540 ---
L3940 ---
1530 mm (60.2 in.)
1750 kg (3860 lbs.)
L4240 ---
1300 mm (51.2 in.)
L4740 ---
L5040
L5240
L5740
--- 1340 mm (52.8 in.) 1430 mm (56.3 in.)
Actual figures
Implement weight W1
and / or size
Max. Drawbar Load W2
Trailer loading weight W3
Max. capacity
L3240
As in the following list
(Shown on the next page)
500 kg (1100 lbs.) 1500 kg (3300 lbs.)
L3540
650 kg (1430 lbs.)
2000 kg (4400 lbs.)
L3940 2500 kg (5500 lbs.)
L4240
3000 kg (6600 lbs.)
L4740
L5040
L5240
L5740
Lower link end max, hydraulic lifting capacity ...W0
Implement weight...........................The implement's weight which can be put on the lower link: W1
Max. drawbar load..........................W2
Trailer loading weight ....................The max. loading weight for trailer (without trailer's weight) : W3
