31OPERATING THE TRACTOR
BLight Switch
Turn the light switch clockwise, and the following lights are
activated on the switch position.
BTurn Signal / Hazard Light Switch
C Hazard Light
1. When the hazard light switch is pushed, the hazard
lights flash, along with the L/H and R/H indicators on
the instrument panel.
2. Push the hazard light switch again to turn off the
hazard lights.
C Turn Signal with Hazard Light
1. To indicate a right turn with the hazard lights already
flashing, turn the switch clockwise.
2. To indicate a left turn with the hazard lights already
flashing, turn the switch counterclockwise.
3. When the left or right turn signal is activated in
combination with the hazard lights, the indicated
turning light will flash and the other will stay on.
C Turn Signal without Hazard Light
1. To indicate a right turn without hazard lights, turn the
switch clockwise.
2. To indicate a left turn without hazard lights, turn the
switch counterclockwise.
3. When the left or right turn signal is activated without
the hazard lights, the indicated turning light will flash
and the other will stay on.
A The hazard light switch is operative when the key
switch is in either the "ON" or "OFF" position.
A The turn signal light switch is only operative when the
key switch is in the "ON" position.
A Be sure to return the turn signal switch to center
position after turning.
2. Selecting light switch positions.
OFF...... Head lights OFF.
....... Head lights dimmed, low beam.
....... Head lights ON, high beam.
(1) Head light switch
(1)Hazard light switch
(2)Turn signal light switch
(3)Hazard / Turn signal indicator
(A) "RIGHT TURN"
(B) "LEFT TURN"
