53OPERATING THE TRACTOR
BFuel Gauge
When the key switch is on, the liquid crystal blocks
indicate the fuel level.
Be careful not to empty the fuel tank. Otherwise air may
enter the fuel system.
Should this happen, the system should be bled. (See
"Bleeding Fuel System" in "SERVICE AS REQUIRED" in
"PERIODIC SERVICE" section.)
A When all the liquid crystal blocks but the leftmost one
of the fuel gauge go out, "FUEL" appears in the liquid
crystal display.
If this should happen during operation, refuel as soon
as possible. (See "Checking and Refueling" in "DAILY
CHECK" in "PERIODIC SERVICE" section.)
BCoolant Temperature Gauge
To avoid personal injury:
A Do not remove radiator cap until coolant
temperature is well below its boiling point.
Then loosen cap slightly to the stop to relieve
any pressure before removing cap completely.
1. With the key switch at "ON" the liquid crystal blocks
indicate the temperature of the coolant. "C" for "cold"
and "H" for "hot."
2. If the indicator reaches the "H" position, engine
coolant is overheated. Check the tractor by referring to
"TROUBLESHOOTING" section.
BTachometer
The tachometer indicates the engine speed.
(1) Fuel gauge (E) "EMPTY"
(F) "FULL"
(1) Coolant temperature gauge
(1)Engine revolution
