73TIRES, WHEELS AND BALLAST
A Wheels with beveled or tapered holes: Use the
tapered side of lug nut.
BFront Wheels (with four wheel drive)
Front tread can not be adjusted.
A Do not turn front discs to obtain wider tread.
A When re-fitting or adjusting a wheel, tighten the bolts
to the following torques then recheck after driving the
tractor 200 m (200 yards) and 10 times of shuttle
movement by 5 m (5 yards), and thereafter according
to service interval.
(See "MAINTENANCE" section.)
A Wheels with beveled or tapered holes: Use the
tapered side of lug nut.
(1) [L3240, L3540, L3940, L4240, L4740]
137 N-m (14 kgf-m, 100 ft-lbs)
[L5040, L5240, L5740]
185 N-m (19 kgf-m, 136 ft-lbs)
