59PTO
BStationary PTO
To park the tractor and use the PTO system (for chipper
or pump, for example), start the PTO system in the
following steps.
1. Apply the parking brakes and place blocks at the tires.
2. Make sure the shift levers are at NEUTRAL, and start
the engine.
3. Tilt the operator's seat forward.
4. Set the PTO clutch control lever to engage"ON".
5. Set the engine speed to provide recommended rear
PTO speed.
A If the PTO system is engaged and you stand up from
the seat or the seat is not tilted forward, the engine
stops automatically after standing up.
BIntelliPanel (TM) Message
1. The PTO rpm can be checked in the display.
(See "INTELLIPANEL(TM)" in "OPERATING THE
TRACTOR" section.)
2. When the PTO system gets engaged (ON), the
indicator lights up.
A Rear PTO "ON"
A Mid-PTO "ON"
(1) Seat
(2) PTO clutch control lever
"ON"
"OFF"
(1)Display
(2)Rear PTO indicator
