93PERIODIC SERVICE
BCleaning Air Cleaner Primary Element
A If the air conditioner condenser is pulled out when
cleaning the air cleaner, the air cleaner cover can be
detached and attached easily.
(See "Cleaning Radiator Screen" in "DAILY CHECK"
in "PERIODIC SERVICE" section.)
1. Remove the air cleaner cover and primary element.
2. Clean the primary element:
(1) When dry dust adheres to the element, blow
compressed air from the inside, turning the
element. Pressure of compressed air must be
under 205 kPa (2.1 kgf/cm , 30 psi).
(2) When carbon or oil adheres to the element, soak
the element in detergent for 15 minutes then wash
it several times in water, rinse with clean water
and dry it naturally. After element is fully dried,
inspect inside of the element with a light and
check if it is damaged or not.
3. Replace air cleaner primary element:
Once every 1000 hours or yearly, whichever comes
first.
(1) Grease fitting (Front axle gear case support) [RH, LH]
(1) Grease fitting (Top link)
(2) Grease fitting (Top link bracket)
(3) Grease fitting (Lifting rod)
(1) Grease fitting (Hydraulic lift cylinders pin)
(1) Grease fitting (Steering joint shaft)
(1) Battery terminals
