49PTO
BLCD Monitor Message
1. The PTO rpm can be checked in the LCD monitor.
(See "LCD MONITOR" in "OPERATING THE
TRACTOR" section.)
2. When the PTO system gets engaged (ON), the
indicator lights up.
BPTO Shaft Cover and Shaft Cap
To avoid personal injury or death:
A Keep the PTO shaft cover in place at all times.
Replace the PTO shaft cap when the PTO is not
in use.
A Before connecting or disconnecting a drive
shaft to PTO shaft, be sure engine is "OFF".
Raise up the PTO shaft cover.
Afterward be sure to return the PTO shaft cover
to the "NORMAL POSITION".
A The universal joint of the PTO drive shaft is technically
limited in its moving angle. Refer to the PTO Drive
Shaft Instructions for proper use.
(1) LCD monitor
(2) PTO clutch indicator
(1) PTO shaft cover
(2) PTO shaft cap
(A) "NORMAL POSITION"
(B) "RAISED POSITION"
To Next Page
