3SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model
M6060 M7060
2WD 4WD 2WD 4WD
Engine
Model V3307-CR-TE4
Type 4 cylinder in-line, Common Rail System, direct injection
Number of cylinders 4
Total displacement cm (cu.in.) 3331 (203)
Bore and stroke mm (in.) 94 x 120 (3.7 x 4.7)
Rated revolution rpm 2400
Low idling revolution rpm 950 to 1000
Net power *1 kW (HP) 47.4 (63.5) 53.0 (71)
PTO power *1
(factory observed)
kW (HP) 41.7 (56) 47.7 (64)
Maximum torque
N-m (ft-lbs) /
rpm
229 (169) / 1400 258 (191) / 1400
Battery capacity 12V, RC: 160 min, CCA 900A
Fuel tank capacity L (U.S.gals.) 90 (23.8)
Engine oil capacity L (U.S.qts.) 12 (12.7)
Coolant capacity L (U.S.qts.) 8 (8.5)
Dimensions
Overall length mm (in.) 3625 (142.7) 3505 (138) 3625 (142.7) 3505 (138)
Overall width
(minimum tread)
mm (in.) 1860 (73)
Overall height mm (in.) 2555 (100.6) 2565 (101)
Wheel base mm (in.) 2145 (84.4) 2110 (83.1) 2145 (84.4) 2110 (83.1)
Tread
Front mm (in.)
1420 to 1820
(55.9 to 71.7)
1420, 1520
(55.9, 59.8)
1420 to 1820
(55.9 to 71.7)
1420, 1520
(55.9, 59.8)
Rear mm (in.)
1420 to 1720
(55.9 to 67.7)
Minimum ground
clearance
mm (in.) 430 (16.9) (Fuel tank stay) 430 (17.3) (Fuel tank stay)
Weight kg (lbs.) 2370 (5226) 2430 (5358) 2380 (5248) 2440 (5380)
Traveling
system
Standard
tire size
Front tires 7.5-16 9.5-24 7.5-16 9.5-24
Rear tires 16.9-28 16.9-30 *2
Clutch Multiple wet disc
Steering Hydraulic Power Steering
Braking system
Mechanically operated wet disc (F8/R8 model)
Hydraulically operated wet disc (F12/R12 model)
Differential Bevel gears with differential lock (Rear)

Kubota M7060 Specifications

General

Engine Type	Diesel
Horsepower	71 HP
PTO Horsepower	64 HP
Cylinders	4
Hydraulic System	Open Center
3-Point Hitch	Category II
Drive	4WD
Gears	12 Forward / 12 Reverse
Lift Capacity	3307 lbs
Displacement	148.5 cu in
Height	96.5 in (245 cm)
