PERIODIC SERVICE80
BCleaning Water Separator
This job should not be done in the field, but in a clean
place.
1. Close the fuel cock.
2. Unscrew the retainer ring and remove the cup, and
rinse the inside with kerosene.
3. Take out the element and dip it in the kerosene to
rinse.
4. After cleaning, reassemble the water separator,
keeping out dust and dirt.
5. Bleed the fuel system.
(See "Bleeding Fuel System" in "SERVICE AS
REQUIRED" in "PERIODIC SERVICE" section.)
BLubricating Grease Fitting [2WD Model]
Detach the cover, and apply bearing grease.
(1) Fuel cock
(2) Retainer ring
(3) Cup
(A) "CLOSE"
(1) O ring
(2) Element
(3) Spring
(4) Red float
(5) Cup
(6) Retainer ring
(1) Front wheel hub cover

Kubota M8540 Specifications

General

Engine Type	Diesel
Engine Model	Kubota V3800-DI-T
Engine Power	85 hp
PTO Power	72 HP
Drive	4WD
Hydraulic System	Open Center
3-Point Hitch	Category II
Displacement	230 cu in (3.8 L)
