Kubota M8540 User Manual

5IMPLEMENT LIMITATIONS
IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by KUBOTA.
Use with implements which are not sold or approved by KUBOTA and which exceed the maximum specifications listed
below, or which are otherwise unfit for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor,
damage to other property and injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use
with improper implements are not covered by the warranty.]
A Implement size may vary depending on soil operating conditions.
Tread (max. width)
Lower link end max.
lifting capacity: W 0
Front
Rear
2WD 4WD
M8540
M9540
2040 mm
(80.3 in.)
1620 mm
(63.8 in.)
1920 mm
(75.6 in.)
Hydraulic high capacity
lift cylinder
equipped:
3900 kg (8600 lbs.)
non-equipped:
2500 kg (5510 lbs.)
Implement weight: W 1 Max. drawbar Load: W 2
Trailer loading weight: W 3
2WD 4WD
M8540
M9540
As in the following list
(Shown on the next page)
1500 kg
(3300 lbs.)
6000 kg
(13200 lbs.)
7000 kg
(15400 lbs.)
Lower link end max, hydraulic lifting capacity.......................................W 0
Implement weight.............................................The implement's weight which can be put on the lower link: W 1
Max. drawbar load............................................W 2
Trailer loading weight.......................................The max. loading weight for trailer (without trailer's weight): W 3

Kubota M8540 Specifications

General

Engine Type	Diesel
Engine Model	Kubota V3800-DI-T
Engine Power	85 hp
PTO Power	72 HP
Drive	4WD
Hydraulic System	Open Center
3-Point Hitch	Category II
Displacement	230 cu in (3.8 L)
