Kubota M8540 User Manual

OPERATING THE TRACTOR18
3. Align set bolt holes and insert both set bolts. Slightly
tighten the set bolts and secure them with the hair pin
cotters.
To avoid personal injury:
A Make sure that both set bolts are properly
installed and secured with the hair pin cotters.
BTo Raise the ROPS to Upright Position
1. Remove both hair pin cotters and set bolts.
2. Raise ROPS to the upright position.
To avoid personal injury:
A Raise the ROPS slowly and carefully.
3. Align set bolt holes and insert both set bolts. Slightly
tighten the set bolts and secure them with the hair pin
cotters.
To avoid personal injury:
A Make sure that both set bolts are properly
installed as soon as the ROPS is in the upright
position and secured with the hair pin cotters.
(1) ROPS
(1) Set bolt
(2) Hair pin cotter
(1) Set bolt
(2) Hair pin cotter
(1) Set bolt
(2) Hair pin cotter

Kubota M8540 Specifications

General

Engine Type	Diesel
Engine Model	Kubota V3800-DI-T
Engine Power	85 hp
PTO Power	72 HP
Drive	4WD
Hydraulic System	Open Center
3-Point Hitch	Category II
Displacement	230 cu in (3.8 L)
