GENERAL
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
G-32
Adjusting Parking Brake Lever
• Stop the engine and chock the wheels before checking
parking brake.
1. Raise the parking brake lever to the parking position while
counting the ratchet sound made by the parking brake lever.
2. If adjustment is needed, loosen the lock nut and adjust the
parking brake cable length with in acceptable limit.
3. Retighten the lock nut.
9Y1211167GEG0038US0
[5] CHECK POINTS OF EVERY 200 HOURS
Changing Engine Oil
1. See page G-21.
9Y1211167GEG0039US0
Replacing Engine Oil Filter Cartridge
1. See page G-22.
9Y1211167GEG0040US0
Replacing Transmission Oil Filter (HST Model)
1. See page G-23.
9Y1211167GEG0041US0
Proper parking brake lever free travel 2 notches (Ratchet sound 2)
(1) Parking Brake Lever
(2) Release Button
(3) Parking Brake Cable
(4) Lock Nut
A : PULL
