GENERAL
L3540-II, L4240-II, L5040-II, L5240-II, L5740-II , WSM
G-71
To avoid personal injury or death:
• Before jacking up the tractor, park it on a firm and level
ground and chock the front wheels.
• Fix the front axle to keep it from swinging.
• Select a jack that withstands the machine weight and set it
up as shown below.
9Y1211167GEG0106US0
[3] TIRE LIQUID INJECTION
Auxiliary weights can be used to increase traction force for plowing in fields or clayey ground.
Another way is to inject water or another liquid, such as a calcium chloride solution in the tires. Water must not
be used in winter since it freezes at 0 °C (32 °F). The calcium chloride solution will not freeze and moreover, affords
higher effect than water since its specific gravity is higher than that of water by about 20 %. Below is an explanation
of calcium chloride solution injection.
• Do not fill the front tires with liquid.
9Y1211167GEG0107US0
Preparation of Calcium Chloride Solution
• When making a calcium chloride solution, do not pour
water over calcium chloride since this results in chemical
reaction which will cause high temperature. Instead add a
small amount of calcium chloride to the water at a time until
the desired solution is achieved.
9Y1211167GEG0108US0
Freezing temp.
Weight of CaCl
2
to be dissolved in 100 L
(26.5 U.S.gals, 22.0 Imp.gals) of water
−5 °C (23 °F) 12 kg (26.4 lbs)
−10 °C (14 °F) 21 kg (46.3 lbs)
−15 °C (5 °F) 28 kg (61.7 lbs)
−20 °C (−4 °F) 34 kg (75.0 lbs)
−25 °C (−13 °F) 40 kg (88.2 lbs)
−30 °C (−22 °F) 44 kg (97.0 lbs)
−35 °C (−31 °F) 49 kg (108 lbs)
−40 °C (−40 °F) 52 kg (114.6 lbs)
−45 °C (−49 °F) 56 kg (123.5 lbs)
−50 °C (−58 °F) 61 kg (134.5 lbs)
(a) Water (b) CaCl
2
(Calcium Chloride)
