11. FRONT WHEEL/SUSPENSION/
STEERING
INSTALLATION
Install the front fork tubes into the upper and
lower fork bridges and the front right and left
turn signal light holders.
Install and tighten the attaching bolts.
Front Fender Installation
Install the front fender between the front fork
tubes, then install and tighten the four bolts.
Torque: 0.8～1.2kg-m
STEERING STEM
REMOVAL
Remove the handlebar. (Refer to 11-3.)
Remove the front fork tubes. (Refer to
11-10.)
Remove the steering stem nut using the lock
nut wrench.
Remove the bearing adjusting nut, top cone
race, steering stem and steel balls.
Place the steel balls in a parts tray so that
they are not lost.
Steering Stem Wrench 5008422
To Next Page
