LEGRAND DX2 Series User Manual

DX2-WS1 - Water Sensors
DX2-WS1 water sensors are available in Rope and Floor Sensor packages. Each package contains one
DX2-WS1 water sensor head with 2 terminals, and either one Rope sensor cable, or one oor mounted
sensor cable.
▶
Connecng the DX2-WS1 Sensor:
When the DX2-WS1 sensor is plugged into the RJ-45 sensor port of a supported managing device, it will
be automacally detected.
The DX2-WS1 provides terminals to aach the water sensing accessories.
• 1 Water Rope input channel with water present status, cable and leakage distance detecon•
• 1 Floor Water Cable input channel with water present status detecon only•
▶ Rope Sensor:
• Detects the presence of water/liquid•
• Detects nearest leak posion on the cable and reports the distance•
• Available in 3.5m, 7m and 10m lengths•
• See How a Cable Water Sensor Works (on page 20)•
16
