LEGRAND DX2 Series User Manual

DX2 Series
A DX2 sensor package consists of two RJ‑45 ports and sensors and/or terminals.
Dierent DX2 sensor packages have a dierent number of sensors, actuators and/or terminals.
See Sensor Comparison (on page 6) for supported oponal hubs.
▶ With standard network patch cables (CAT5e or higher), you can:
• Connect a DX2 sensor to a supported managing product with the "RJ‑45" SENSOR port.•
Excepon: For a device with an "RJ‑12" SENSOR port, an RJ‑12 to RJ‑45 adapter cable (part number:
RJ12M-RJ45M) is needed.
• Daisy chain DX2 sensor packages.•
Warning: Do NOT use a crossover cable for connection.
In This Chapter
DX2-DH2C2 Door Handle Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
DX2 Temperature and Humidity Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
DX2-T1DP1 - Temperature and Dierenal Air Pressure Sensors. . . . . . . . . . . . . . 13
DX2-AF1 - Airow Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DX2-WS1 - Water Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
DX2-CC2 Contact Closure Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cascading DX2 Sensor Packages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
DX2-D2 Dual Dry-Contact Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
DX2-D2C6 Dry Contact Contact Closure Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
DX2-PD2 - Dual Powered Dry-Contact Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
DX2-PD2C5 Powered Dry Contact and Contact Closure Sensor. . . . . . . . . . . . . . . . 31
DX2-PS - Parcle Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
DX2-PIR Proximity Infrared Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
DX2-DH2C2 Door Handle Controller
DX2‑DH2C2 provides a cabinet access control soluon. Connect supported door handles to DX2‑DH2C2,
then connect DX2‑DH2C2 to a supported managing device, and you will be able to control a cabinet's
door handles via the device's web interface.
▶ Door handles supported by DX2‑DH2C2:
a. SouthCo H3-EM series:a.
7
