▶ Mounng the Floor Sensor:
• See Floor-mounted Water Sensor (on page 18).•
DX2-WS1 LED States
The water sensor shows alerts or rmware updates through its LED states.
LED states Descripon
O Water Leakage state is normal.
Flashing
(1 ash and 1 o)
Water Leakage enters either alarmed state: warning or
crical.
High-speed ashing Sensor rmware is being updated. See Sensor Firmware
Update (on page 58).
Floor-mounted Water Sensor
The oor‑mounted water sensor has a at boom so it can stand on the ground. The water detector's
dimension is 63.5 mm x 13.25 mm x 13.2 mm (W x L x D).
Use one of the following methods to ax this detector to the ground:
• Screw the detector to the ground with your own screws. To avoid breaking the detector's enclosure,•
do not over ghten the screws.
• Put something weighing around 100 to 250 grams (0.22 to 0.55 pounds) into the empty bag shipped•
with this water sensor. Then use cable es to wrap the bag right above the detector. Make sure the
detector is not lted so that its boom evenly contacts the ground.
Number Item
Water detector.
18
