LEGRAND DX2 Series User Manual

DX Series
A DX sensor package consists of terminals, sensors and two RJ‑45 ports.
Dierent DX sensor packages have a dierent number of terminals. Every pair of terminals is a channel
for connecng a sensor or actuator.
DX contact closure channels support the following types of sensors:
• Door open/closed detecon•
• Door lock detecon•
• Smoke detecon•
• Vibraon detecon•
DX contact closure channels do NOT support any water detecon sensors.
Important: Third-party leakage detectors may also not work, so you must test them
before using.
No sensor cables are shipped with DX sensor packages.
▶
With standard network patch cables (CAT5e or higher), you can:
• Connect a DX sensor to a supported managing device with the RJ‑45 SENSOR port.•
Excepon: For a device with an "RJ‑12" SENSOR port, an RJ‑12 to RJ‑45 adapter cable (part number:
RJ12M-RJ45M) is needed.
• Daisy chain DX sensor packages.•
Warning: Do NOT use a crossover cable for connecon.
In This Chapter
DX-D2C6 Dry Contact and Contact Closure Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . 37
DX-PD2C5 - Powered Dry Contact and Contact Closure. . . . . . . . . . . . . . . . . . . . . . 40
DX-PIR Proximity Infrared Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
DX-D4C3 Dry Contact and Contact Closure Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . 45
DX-VBR Vibraon Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Making Connecons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Adjusng DIP Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
DX-D2C6 Dry Contact and Contact Closure Sensor
DX‑D2C6 has seven channels for both contact closure sensors and dry contact signal actuators.
37
