Behaviour in the event of mains switching, mains failure or controller inhibit
Controller inhibit
10
Function library
10.5
10.5.2
L
10.5-3
EDS82EV903-1.0-11/2002
10.5.2 Controller inhibit
If the controller inhibit is active, the power outputs are inhibited.
l The drive idles to standstill without torque.
l Keypad status display: Pulse inhibit c
l Status display of the controller: The green LED is blinking.
}
}}
} Danger!
Do not use controller inhibit (DCTRL1-CINH) as emergency off.
The controller inhibit only inhibits the power outputs and does
not disconnect the controller from the mains!
The drive could restart any time.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0040* Controller inhibit
-0- controller inhibited (CINH)
Controller can only be enabled if X3/28 = ^ 10.5-3
v
(CINH)
-1- Controller enabled (CINH)
HIGH
l Via terminal X3/28:
– LOW level at the terminal activates the controller inhibit (cannot be
inverted)
– HIGH level releases the controller again
l Via digital signal (linking C0410/10 with a signal source):
– LOW level at the signal source activates the controller inhibit (level
inversion is possible with C0411)
– HIGH level releases the controller again
l Via keypad (condition: C0469 = 1):
– s activates the controller inhibit
– u releases the controller again
l Via code C0040:
– C0040 = 0 activates the controller inhibit
– C0040 = 1 releases the controller again
)
))
) Note!
l The sources for controller inhibit are ANDed, i. e. the drive only
restarts when the controller inhibit is cancelled at all signal
sources.
l The restart begins with an output frequency of 0 Hz, i.e. if the
flying-restart circuit is not activated, still rotating masses can
lead to generative overload.
