Conditions for a trouble-free network of several drives
Possible combinations of Lenze controllers in a network of several drives
12
Network of several drives
12.4
12.4.1
L
12.4-1
EDS82EV903-1.0-11/2002
12.4 Conditions for a trouble-free network of several drives
(
((
( Stop!
Only connect controllers with the same mains voltage ranges or
DC-bus voltage ranges (see table below).
Adapt the thresholds for brake units and brake transistors.
All supply terminals must only be operated with the prescribed
mains choke/mains filter!
(¶ 12.5-2)
12.4.1 Possible combinations of Lenze controllers in a network of several drives
Type Data E82EVXXXK2C
E82EVXXXK2C
 1 / N / PE / A C / 180 V - 0 % ... 264 V + 0%
45 Hz - 0 % ... 65 Hz + 0 %
 DC 140 V ... 370 V
 DC 380 V
Type Data E82EVXXXK4C 822X 93XX
E82EVXXXK4C
 3 / PE / AC / 320 V - 0 % ... 550 V + 0 %
45 Hz - 0 % ... 65 Hz + 0 %
 DC 450 V ... 775 V
 DC 725 V/765 V
822X
824X

3 / PE / AC / 320 V - 0 % ... 528 V + 0 %
48 Hz - 0 % ... 62 Hz + 0 %
8
2
4
X

DC 460 V ... 740 V

DC 725 V/765 V
821X

3 / PE / AC / 320 V - 0 % ... 510 V + 0 %
45 Hz - 0 % ... 65 Hz + 0 %

DC 450 V ... 715 V

DC 725 V/765 V
93XX

3 / PE / AC / 320 V - 0 % ... 528 V + 0 %
48 Hz - 0 % ... 62 Hz + 0 %

DC 460 V ... 740 V

DC 725 V/765 V
 Max. permissible mains voltage range
 Permissible DC-bus voltage range
 Threshold of external brake unit (option)
)
))
) Note!
If the requirements stated above are met, the Lenze controllers
type 821X and type 824X can also be integrated into the network.
Combinations in the 230 V mains
Combinations in the 400 V mains
