Commissioning
Vector control
6
102
EDK82MV752 DE/EN/FR 7.2
6.5 Vector control
The following instructions apply to controllers equipped with a standard−I/O function
module and a three−phase AC motor which has been selected according to a power−based
assignment.
Switch−on sequence Comment
1. Connect keypad
2. Ensure that controller inhibit is active after mains connection
Terminal X3/28 = LOW
3. Switch on the mains
4.
5.
The keypad is in "Disp" mode after approx. 2 s and indicates the
output frequency (C0050)
The USEr menu is active
6. Go to the ALL menu
7. Change to the ! mode to configure the basic settings for your
drive
Blinking on the display: 0050
8. Adapt the terminal configuration to the wiring (C0007)
Lenze setting: −0−, i. e.
E1: JOG1/3 fixed setpointselection
E2: JOG2/3
E3: DCB DC brake
E4: CW/CCW rotation
9. Set the minimum output frequency (C0010)
Lenze setting: 0.00 Hz
10. Set the maximum output frequency (C0011)
Lenze setting: 50.00 Hz
11. Set the acceleration time T
ir
(C0012)
Lenze setting: 5.00 s
12. Set the deceleration time T
if
(C0013)
Lenze setting: 5.00 s
13. Activate the operating mode "vector control" (C0014 = 4)
Lenze setting: Linear V/f characteristic control (C0014 = 2)
14. Adapt the voltage/current range for the analog setpoint selection
(C0034)
Lenze setting: −0−, (0 ... 5 V/0 ... 10 V/0 ... 20 mA)
Set the DIP switch on the standard I/O to the same
range (see Mounting Instructions for the standard
I/O)
15. Enter the motor data See motor nameplate
A Rated motor speed (C0087)
Lenze setting: 1390 rpm
B Rated motor current (C0088)
Lenze setting: Depending on the controller
Enter the value for the motor circuit configuration
(star/delta) selected!
C Rated motor frequency (C0089)
Lenze setting: 50 Hz
D Rated motor voltage (C0090)
Lenze setting: Depending on the controller
Enter the value for the motor circuit configuration
(star/delta) selected!
E Motor cosj (C0091)
Lenze setting: Depending on the controller
