Lenze E82MV752 User Manual

Technical data
Dimensions
3

79
EDK82MV752 DE/EN/FR 7.2
3.3 Dimensions
82mot443
Type a [mm] b [mm] c [mm] d [mm] e [mm]
E82MV302_4B
E82MV402_4B
E82MV552_4B
E82MV752_4B
214
(incl. seal)
163
(208, incl. fan module)
150
329
(incl. seal)
15
Mechanical design
Type Screwed connections Weight
E82MV302_4B
E82MV402_4B
E82MV552_4B
E82MV752_4B
3 × M25, 4 × M16
(Thread length 10 mm, without counternut)
9.9 kg
(11.7 kg incl. fan
module)
Dimensions of the fan module E82ZMV
82mot460
206
172
180
140
5.5
320
5656
60
60
16
206
