Mechanical installation
motec with motor or geared motor
4
80
EDK82MV752 DE/EN/FR 7.2
4 Mechanical installation
4.1 motec with motor or geared motor
Danger!
ƒ All control terminals only have basic insulation (single isolating distance)
after connecting a PTC thermistor or a thermal contact.
ƒ Protection against accidental contact in case of a defective isolating
distance is only guaranteed through external measures, e. g. double
insulation.
8200mot448
91
3 x M25
4 x M16
Activate motor temperature monitoring with C0119 (e.g. C0119 = 1)!
