Communication manual 8400 motec PROFIBUS
Parameter data transfer
DRIVECOM parameter data channel (DP-V0)
50 L EDS84DMOTPBUS EN 3.0 - 11/2011
9.2.7.2 Write request: Setting the deceleration time for quick stop (QSP)
In the controller, the deceleration time for quick stop (QSP) is to be set to 50 ms.
 Code to be written: C00105
Byte 1: Service (request)
 Request = 0t110010
bin
– Bit 0 ... 2 = 010
bin
for write request
– Bit 3 = 0 (reserved)
– Bit 4/5 = 11
bin
for 4-byte data length
– Bit 6 = handshake bit (t ≡ status is changed in the response telegram)
– Bit 7 = status bit (only relevant for the response telegram)
Byte 2: Subindex
 Subindex = 0 because code C00105 does not contain any subindices.
Bytes 3 + 4: Index
 Index = 24575 - code number = 24575 - 105 = 24470 = 0x5F96
– Byte 3 (high byte) = 0x5F
– Byte 4 (low byte) = 0x96
Bytes 5 ... 8: Data
 The parameter value of 0.05 s to be set is multiplied by the code-specific factor of
"1000" and entered in the user data:
– Data 1 ... 4 = 0.05 [s] x 1000 (internal factor) = 50 = 0x00000032
Result:
 Request telegram from master to drive:
 Response telegram from drive to master (for correct execution):
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index high byte Index low byte Data 4 Data 3 Data 2 Data 1
0x72 0x00 0x5F 0x96 0x00 0x00 0x00 0x32
0t110010
bin
00000000
bin
01011111
bin
10010110
bin
00000000
bin
00000000
bin
00000000
bin
00110010
bin
Waiting for change of handshake bit 6 in service byte 1 of the response
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index high byte Index low byte Data 4 Data 3 Data 2 Data 1
0x40 0x00 0x5F 0x96 0x00 0x00 0x00 0x32
0t000000
bin
00000000
bin
01011111
bin
10010110
bin
00000000
bin
00000000
bin
00000000
bin
00110010
bin
