EDS84DMOTPBUS EN 3.0 - 11/2011 L 89
Communication manual 8400 motec PROFIBUS
Parameter reference
Table of attributes
13.3 Table of attributes
The table of attributes contains information required for a communication with the
Inverter Drives 8400 motec via parameters.
How to read the table of attributes:
Column Meaning Entry
Code Parameter designation Cxxxxx
Name Parameter short text (display text) Text
Index dec Index by which the parameter is addressed.
The subindex for array variables corresponds to the
Lenze subcode number.
24575 - Lenze code number Is only required for access via a bus
system.
hex 5FFF
h
- Lenze code number
Data DS Data structure E Single variable
(only one parameter element)
A Array variable
(several parameter elements)
DA Number of array elements (subcodes) Number
DT Data type BITFIELD_8 1 byte, bit-coded
BITFIELD_16 2 bytes, bit-coded
BITFIELD_32 4 bytes, bit-coded
INTEGER_8 1 byte with sign
INTEGER_16 2 bytes with sign
INTEGER_32 4 bytes with sign
UNSIGNED_8 1 byte without sign
UNSIGNED_16 2 bytes without sign
UNSIGNED_32 4 bytes, without sign
VISIBLE_STRING ASCII string
OCTET_STRING
Factor Factor for data transmission via a bus system,
depending on the number of decimal positions
Factor 1 ≡ no decimal positions
10 ≡ 1 decimal position
100 ≡ 2 decimal positions
1000 ≡ 3 decimal positions
Access R Read access ; Reading permitted
W Write access ; Writing permitted
CINH Controller inhibit required ; Writing is only possible if controller inhibit is set
